FAG 31313-XL-DF-A120-160

Specifications

Brand	FAG
Item Number	31313-XL-DF-A120-160 FAG
Manufacturer Part Number	0880632084081
Also known as	31313-DF-A120-160
EAN	4054371048464
Category	Tapered Roller Bearing Single Row (paired metric)

Weight and Dimensions

Inner (d) MM	65
Outer (D) MM	140
Width (B) MM	72
Inner (d) Inch	2.5591
Outer (D) Inch	5.5118
Width (B) Inch	2.8346
Weight (kg)	5.05 kg

Product Properties

Tapered Roller Pair Internal Play

120-160µm

Data from Schaeffler (medias)

Inner ring total width (2B) mm	66
Radial Static Load Rating C0r (N)	375000
Radial Dynamic Load Rating Cr (N)	330000
Basic static load rating, radial (C 0r)	"375000.0000"
Limiting speed (n G)	5500
Outer ring total width (2T) mm	72
Thermal speed rating (n u03d1r)	3650
ECLASS number	23-05-09-10
ECLASS2 number	23-05-09-10
Medias description	Tapered roller bearing set 313..-XL-DF, X-arrangement

Suffix description

XL	X-Life
DF	Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings
A120-160	Axial Clearance In µm
