FAG 24122-BE-XL-2VSR-C4 Image 2
Visual product photo and picture of the product.
Price: 774.26 $
Specifications
Weight and Dimensions
| Inner (d) MM |
110 |
| Outer (D) MM |
180 |
| Width (B) MM |
69 |
| Inner (d) Inch |
4.3307 |
| Outer (D) Inch |
7.0866 |
| Width (B) Inch |
2.7165 |
| Weight (kg) |
6.9 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
2RS2 - Fluoro Rubber Seals / High Temperature |
| Cage Type |
S - Steel or Standard Cage |
| Radial Internal Play |
C4 Internal Play (Higher than C3) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
69 |
| Radial Static Load Rating C0r (N) |
750000 |
| Radial Dynamic Load Rating Cr (N) |
530000 |
| Basic static load rating, radial (C 0r) |
"750000.0000" |
| Limiting speed (n G) |
830 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Sealed spherical roller bearings 241..-BE-2VSR, lip seals on both sides, for continuous casting machines |
Suffix description
| BE |
Maximum Capacity Design |
| XL |
X-Life |
| 2VSR |
Sheet Steel Reinforced Rubbing Seals Of Fluoro Rubber (FPM) At Both Sides Of The Bearing. Grease Fill 70 To 100% With A Plyurea High Temperature Grease. Annular Groove And Three Lubricating Holes In The Outer Ring |
| C4 |
Bearing Internal Clearance Greater Than C3 |
