FAG 24122-BE-XL-2VSR-C4
Price: 774.26 $
Specifications
| Brand | FAG |
| Item Number | 24122-BE-XL-2VSR-C4 FAG |
| Manufacturer Part Number | 0755881020040 |
| Also known as |
24122-BE-2VSR-C4 |
| EAN | 4012802689297 |
| Category | Spherical Roller Bearing |
| Inner (d) MM | 110 |
| Outer (D) MM | 180 |
| Width (B) MM | 69 |
| Inner (d) Inch | 4.3307 |
| Outer (D) Inch | 7.0866 |
| Width (B) Inch | 2.7165 |
| Weight (kg) | 6.9 kg |
| Bore | C - Cylindrical Bore |
| Lubrication Enhancement | W33 - Lubrication Groove and 3 Holes |
| Seal | 2RS2 - Fluoro Rubber Seals / High Temperature |
| Cage Type | S - Steel or Standard Cage |
| Radial Internal Play | C4 Internal Play (Higher than C3) |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Width (b) mm | 69 |
| Radial Static Load Rating C0r (N) | 750000 |
| Radial Dynamic Load Rating Cr (N) | 530000 |
| Basic static load rating, radial (C 0r) | "750000.0000" |
| Limiting speed (n G) | 830 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Sealed spherical roller bearings 241..-BE-2VSR, lip seals on both sides, for continuous casting machines |
| BE | Maximum Capacity Design |
| XL | X-Life |
| 2VSR | Sheet Steel Reinforced Rubbing Seals Of Fluoro Rubber (FPM) At Both Sides Of The Bearing. Grease Fill 70 To 100% With A Plyurea High Temperature Grease. Annular Groove And Three Lubricating Holes In The Outer Ring |
| C4 | Bearing Internal Clearance Greater Than C3 |
