FAG 23132-E1A-XL-M-C4 Image 3
Visual product photo and picture of the product.
Price: 725.26 $
Specifications
Weight and Dimensions
| Inner (d) MM |
160 |
| Outer (D) MM |
270 |
| Width (B) MM |
86 |
| Inner (d) Inch |
6.2992 |
| Outer (D) Inch |
10.6299 |
| Width (B) Inch |
3.3858 |
| Weight (kg) |
20 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| Radial Internal Play |
C4 Internal Play (Higher than C3) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
86 |
| Radial Static Load Rating C0r (N) |
1550000 |
| Radial Dynamic Load Rating Cr (N) |
1160000 |
| Basic static load rating, radial (C 0r) |
"1550000.0000" |
| Limiting speed (n G) |
2490 |
| Reference speed (n u03d1r) |
1560 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearings 231..-E1A, main dimensions to DIN 635-2 |
Suffix description
| E1 |
Increased Capacity Design |
| A |
Modified Internal Construction |
| XL |
X-Life |
| M |
Solid Brass Cage, Guided By Rollers |
| C4 |
Bearing Internal Clearance Greater Than C3 |
