FAG 23132-E1A-XL-M-C4

FAG 23132-E1A-XL-M-C4
FAG 23132-E1A-XL-M-C4 rulman resim 1
FAG 23132-E1A-XL-M-C4 rulman resim 2
FAG 23132-E1A-XL-M-C4 rulman resim 3
FAG 23132-E1A-XL-M-C4 rulman resim 4
FAG 23132-E1A-XL-M-C4 rulman resim 5
FAG 23132-E1A-XL-M-C4 rulman resim 6
FAG 23132-E1A-XL-M-C4 rulman resim 7
FAG 23132-E1A-XL-M-C4 rulman resim 8
Price: 725.26 $
Specifications
Brand FAG
Item Number 23132-E1A-XL-M-C4 FAG
Manufacturer Part Number 0190315560040
Also known as 23132-E1A-M-C4
EAN 4026677872111
Category Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM 160
Outer (D) MM 270
Width (B) MM 86
Inner (d) Inch 6.2992
Outer (D) Inch 10.6299
Width (B) Inch 3.3858
Weight (kg) 20 kg
Product Properties
Bore C - Cylindrical Bore
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type M - Brass Cage
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Width (b) mm 86
Radial Static Load Rating C0r (N) 1550000
Radial Dynamic Load Rating Cr (N) 1160000
Basic static load rating, radial (C 0r) "1550000.0000"
Limiting speed (n G) 2490
Reference speed (n u03d1r) 1560
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 231..-E1A, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
A Modified Internal Construction
XL X-Life
M Solid Brass Cage, Guided By Rollers
C4 Bearing Internal Clearance Greater Than C3
