FAG 21309-E1-XL-K-TVPB-C3

FAG 21309-E1-XL-K-TVPB-C3
FAG 21309-E1-XL-K-TVPB-C3 rulman resim 1
FAG 21309-E1-XL-K-TVPB-C3 rulman resim 2
FAG 21309-E1-XL-K-TVPB-C3 rulman resim 3
FAG 21309-E1-XL-K-TVPB-C3 rulman resim 4
Price: 62.52 $
Specifications
Brand FAG
Item Number 21309-E1-XL-K-TVPB-C3 FAG
Manufacturer Part Number 0190058650030
Also known as 21309-E1-K-TVPB-C3
EAN 4026677805553
Category Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 100
Width (B) MM 25
Inner (d) Inch 1.7717
Outer (D) Inch 3.937
Width (B) Inch 0.9843
Weight (kg) 0.947 kg
Product Properties
Bore K - 1:12 Tapered Bore (Standard for Most Types)
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type P - Plastic Molded Cage
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Width (b) mm 25
Radial Static Load Rating C0r (N) 130000
Radial Dynamic Load Rating Cr (N) 129000
Basic static load rating, radial (C 0r) "130000.0000"
Limiting speed (n G) 9000
Reference speed (n u03d1r) 4750
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 213..-E1-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12
Suffix description
E1 Increased Capacity Design
XL X-Life
K Tapered Bore, Taper 1:12
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
C3 Internal Clearance Larger Than Normal
