FAG 21304-E1-XL-TVPB

FAG 21304-E1-XL-TVPB
FAG 21304-E1-XL-TVPB rulman resim 1
FAG 21304-E1-XL-TVPB rulman resim 2
FAG 21304-E1-XL-TVPB rulman resim 3
FAG 21304-E1-XL-TVPB rulman resim 4
Price: 49.61 $
Specifications
Brand FAG
Item Number 21304-E1-XL-TVPB FAG
Manufacturer Part Number 0167022040000
Also known as 21304-E1-TVPB
EAN 4026677808080
Category Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 52
Width (B) MM 15
Inner (d) Inch 0.7874
Outer (D) Inch 2.0472
Width (B) Inch 0.5906
Weight (kg) 0.16 kg
Product Properties
Bore C - Cylindrical Bore
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type P - Plastic Molded Cage
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Width (b) mm 15
Radial Static Load Rating C0r (N) 33000
Radial Dynamic Load Rating Cr (N) 41000
Basic static load rating, radial (C 0r) "33000.0000"
Limiting speed (n G) 16000
Reference speed (n u03d1r) 9700
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 213..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
