FAG 1309-K-TVH-C3

FAG 1309-K-TVH-C3
FAG 1309-K-TVH-C3 rulman resim 1
FAG 1309-K-TVH-C3 rulman resim 2
FAG 1309-K-TVH-C3 rulman resim 3
FAG 1309-K-TVH-C3 rulman resim 4
Price: 51.86 $
Specifications
Brand FAG
Item Number 1309-K-TVH-C3 FAG
Manufacturer Part Number 0389035630030
EAN 4012801025072
Category Self Aligning Ball Bearing Double Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 100
Width (B) MM 25
Inner (d) Inch 1.7717
Outer (D) Inch 3.937
Width (B) Inch 0.9843
Weight (kg) 0.942 kg
Product Properties
Bore K - 1:12 Tapered Bore (Standard for Most Types)
Seal No Seal
Cage Type P - Plastic Molded Cage
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 25
Radial Static Load Rating C0r (N) 12700
Radial Dynamic Load Rating Cr (N) 38500
Basic static load rating, radial (C 0r) "12700.0000"
Limiting speed (n G) 7500
Reference speed (n u03d1r) 6700
ECLASS number 23-05-08-06
ECLASS2 number 23-05-08-06
Medias description Self-aligning ball bearing 13..-K-TVH
Suffix description
K Tapered Bore, Taper 1:12
TVH Solid Cage Made From Glass Fibre Reinforced Polyamide 66
C3 Internal Clearance Larger Than Normal
