URB NN3009KMP51NAW33 Image 2
Visual product photo and picture of the product.
Price: 113.86 $
Specifications
Weight and Dimensions
| Inner (d) MM |
45 |
| Outer (D) MM |
75 |
| Width (B) MM |
23 |
| Inner (d) Inch |
1.7717 |
| Outer (D) Inch |
2.9528 |
| Width (B) Inch |
0.9055 |
| Weight (kg) |
0.392 kg
|
Product Properties
| Bore |
K - 1:12 Tapered Bore (Standard for Most Types) |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
W33 |
| Radial Internal Play |
C1 Internal Play (Less than C2) |
| Precision |
P5 Precision (Higher than P6) |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Suffix description
| K |
Tapered Bore, Taper 1:12 |
| M |
Machined Brass Cage, Located On The Rolling Elements |
| P51 |
Combination Of P5 (Dimensional And Running Accuracy To ISO Tolerance Class 5 (Better Than P6)) And C1 (Radial Clearance And Reduced Levels Of Vibration) |
| NA |
Radial Clearance, Non-Interchangeable Elements |
| W33 |
Lubrication Groove And Three Holes In Bearing Outer Ring |
