SKF S7016ACDGA/HCP4A Image 2
Visual product photo and picture of the product.
Price: 1,170.21 $
Specifications
Weight and Dimensions
| Inner (d) MM |
80 |
| Outer (D) MM |
125 |
| Width (B) MM |
22 |
| Inner (d) Inch |
3.1496 |
| Outer (D) Inch |
4.9213 |
| Width (B) Inch |
0.8661 |
| Weight (kg) |
0.85 kg
|
Product Properties
| Seal |
2RL - Low Friction NBR-seal |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
H4 - Hybrid / Ceramic Balls / P4 |
| Contact Angle |
25 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
GA - Light Preload |
| Lubrication |
Standard Lubrication |
Suffix description
| ACD |
25° Contact Angle |
| GA |
Single Row Angular Contact Ball Bearing For Universal Matching. Two Bearings Arranged Back-To-Back Or Face-To-Face Will Have A Light Preload |
| HC |
Bearing Or Bearing Components Of Ceramic |
| P4A |
Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4 |
