SKF NU215ECM/C4HVA3091 Image 3
Visual product photo and picture of the product.
Price: 923.72 $
Specifications
Weight and Dimensions
| Inner (d) MM |
75 |
| Outer (D) MM |
130 |
| Width (B) MM |
25 |
| Inner (d) Inch |
2.9528 |
| Outer (D) Inch |
5.1181 |
| Width (B) Inch |
0.9843 |
| Weight (kg) |
1.4 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Int. Play Upper Half C4 Range |
| Precision |
Breakdown Voltage 1000v |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Suffix description
| EC |
Optimized Internal Design Incorporating More And/Or Larger Rollers And With Modified Roller/End Flange Contact |
| M |
Two-Piece Machined Brass Cage, Roller Centered |
| C4H |
Int. Play Upper Half C4 Range |
| VA3091 |
Combination of VA301 (Bearing For Railway Vehicle Traction Motors) And |
| VL0241 |
Aluminium Oxide Coated Outside Surface Of The Outer Ring For Electrical Resistance Up To 1.000v DC) |
