SKF NU206ECML/C3S1 Image 3
Visual product photo and picture of the product.
Price: 152.80 $
Specifications
Weight and Dimensions
| Inner (d) MM |
30 |
| Outer (D) MM |
62 |
| Width (B) MM |
16 |
| Inner (d) Inch |
1.1811 |
| Outer (D) Inch |
2.4409 |
| Width (B) Inch |
0.6299 |
| Weight (kg) |
0.227 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
ML - Brass Cage Inner/Outer Ring Centered |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Heat Stabilization |
S1 - Temperatures up to 200 °C |
Suffix description
| EC |
Optimized Internal Design Incorporating More And/Or Larger Rollers And With Modified Roller/End Flange Contact |
| ML |
One-Piece Form-Turned Window-Type Brass Cage, Inner Or Outer Ring Centered |
| C3 |
Internal Clearance Larger Than Normal |
| S1 |
Bearing Rings Or Washers Dimensionally Stabilized For Use At Operating Temperatures Up To +200°C (392°F) |
