SKF 7314BEGAM Image 2
Visual product photo and picture of the product.
Price: 293.91 $
Specifications
Weight and Dimensions
| Inner (d) MM |
70 |
| Outer (D) MM |
150 |
| Width (B) MM |
35 |
| Inner (d) Inch |
2.7559 |
| Outer (D) Inch |
5.9055 |
| Width (B) Inch |
1.378 |
| Weight (kg) |
2.9 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| Precision |
Standard Precision |
| Contact Angle |
40 degrees |
| Pairing |
No pairing |
| Axial Internal Clearance / Preload |
GA - Light Preload |
| Lubrication |
Standard Lubrication |
Suffix description
| BE |
Single Row Angular Contact Ball Bearing With A 40° Contact Angle And Optimized Internal Design |
| GA |
Single Row Angular Contact Ball Bearing For Universal Matching. Two Bearings Arranged Back-To-Back Or Face-To-Face Will Have A Light Preload |
| M |
Machined Window-Type Brass Cage, Ball Centered, Different Designs Are Identified By A Figure, e.g. M1 |
