SKF 709CEGA/HCP4ALT20F2 Image 2
Visual product photo and picture of the product.
Price: 302.89 $
Specifications
Weight and Dimensions
| Inner (d) MM |
9 |
| Outer (D) MM |
24 |
| Width (B) MM |
7 |
| Inner (d) Inch |
0.3543 |
| Outer (D) Inch |
0.9449 |
| Width (B) Inch |
0.2756 |
| Weight (kg) |
0.014 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
H4 - Hybrid / Ceramic Balls / P4 |
| Contact Angle |
15° Contact High Speed Design |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
GA - Light Preload |
| Lubrication |
Higher and Lower Temperature Grease |
Suffix description
| CE |
15° Contact Angle And (E) Small Size Balls |
| GA |
Single Row Angular Contact Ball Bearing For Universal Matching. Two Bearings Arranged Back-To-Back Or Face-To-Face Will Have A Light Preload |
| HC |
Bearing Or Bearing Components Of Ceramic |
| P4A |
Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4 |
| LT20 |
Isoflex SUPER LDS 18 Grease Fill For Low Temperatures e.g. -50 ~ 80°C |
| F2 |
Unknown |
