SKF 7009CE/HCP4ADT Image 2
Visual product photo and picture of the product.
Price: 959.31 $
Specifications
Weight and Dimensions
| Inner (d) MM |
45 |
| Outer (D) MM |
75 |
| Width (B) MM |
32 |
| Inner (d) Inch |
1.7717 |
| Outer (D) Inch |
2.9528 |
| Width (B) Inch |
1.2598 |
| Weight (kg) |
0.46 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
H4 - Hybrid / Ceramic Balls / P4 |
| Contact Angle |
15° Contact High Speed Design |
| Pairing |
DT - Tandem Arrangement, 2 |
| Axial Internal Clearance / Preload |
No Preload |
| Lubrication |
Standard Lubrication |
Suffix description
| CE |
15° Contact Angle And (E) Small Size Balls |
| HC |
Bearing Or Bearing Components Of Ceramic |
| P4A |
Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4 |
| DT |
Two Single Row Deep Groove Ball Bearings, Single Row Angular Contact Ball Bearings Or Single Row Tapered Roller Bearings Matched For Mounting In A Tandem Arrangement |
