SKF 7005CD/P4ADBG20 Image 2
Visual product photo and picture of the product.
Price: 322.92 $
Specifications
Weight and Dimensions
| Inner (d) MM |
25 |
| Outer (D) MM |
47 |
| Width (B) MM |
24 |
| Inner (d) Inch |
0.9843 |
| Outer (D) Inch |
1.8504 |
| Width (B) Inch |
0.9449 |
| Weight (kg) |
0.15 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
P4 Precision (Higher than P5) |
| Contact Angle |
15 degrees |
| Pairing |
DB - O-arrangement, 2 |
| Axial Internal Clearance / Preload |
DU - 2 Pair, Universally Ground |
| Lubrication |
Standard Lubrication |
Suffix description
| CD |
15° Contact Angle |
| P4A |
Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4 |
| DBA |
Two Single Row Deep Groove Ball Bearings, Single Row Angular Contact Ball Bearings Or Single Row Tapered Roller Bearings Matched For Mounting In A Back-To-Back Arrangement |
| G20 |
The Number Is The Mean Preload Value Of The Set Expressed In daN |
