SKF 6315-2RS1/C3WT Image 3
Visual product photo and picture of the product.
Price: 275.94 $
Specifications
Weight and Dimensions
| Inner (d) MM |
75 |
| Outer (D) MM |
160 |
| Width (B) MM |
37 |
| Inner (d) Inch |
2.9528 |
| Outer (D) Inch |
6.2992 |
| Width (B) Inch |
1.4567 |
| Weight (kg) |
3.17 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
2RS - Rubber Seal on Two Sides |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Lubrication |
High Temperature Grease |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Suffix description
| 2RS1 |
Sheet Steel Reinforced Contact Seal Of Acrylonitrile-Butadiene Rubber (NBR) On Both Sides Of The Bearing |
| C3 |
Internal Clearance Larger Than Normal |
| WT |
Grease Fill For Low As Well As High Temperature e.g. -40 ~ 160°C. WT Or A Two-Figure Number Following WT Identifies The Actual Grease. An Additional Letter Or Letter/ Figure Combination As Mentioned Under u201cHTu201d Identifies Filling Degrees Other Than Standard |
