SKF 6309-2Z/C2ELHT23 Image 2

Visual product photo and picture of the product.

Price: 68.33 $

Specifications

Brand	SKF
Item Number	6309-2Z/C2ELHT23 SKF
Also known as	6309-2Z/C2E
EAN	7316570399950
Category	Deep Groove Ball Bearings Single Row

Weight and Dimensions

Inner (d) MM	45
Outer (D) MM	100
Width (B) MM	25
Inner (d) Inch	1.7717
Outer (D) Inch	3.937
Width (B) Inch	0.9843
Weight (kg)	0.848 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	ZZ/2Z - Steel Seal on Two Sides
Cage Type	S - Steel or Standard Cage
External Modification	No External Modification
Radial Internal Play	C2 + Reinforced Ball Set
Precision	Standard Precision
Lubrication	L - -50°C/+140°C
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Special Treatment	No Special Treatment

Suffix description

2Z	Shield Of Pressed Sheet Steel On Both Sides Of The Bearing
C2E	Bearing Internal Clearance Smaller Than Normal, Reinforced Ball Set
LHT23	Lithium Grease, Wide Range, 26 cSt @ 40°C, Range -50 ~ 140°C. A Two-Figure Number Following LHT Identifies The Actual Grease
