SKF 6301-ZTN9/C3MT33 Image 2
Visual product photo and picture of the product.
Price: 16.40 $
Specifications
Weight and Dimensions
| Inner (d) MM |
12 |
| Outer (D) MM |
37 |
| Width (B) MM |
12 |
| Inner (d) Inch |
0.4724 |
| Outer (D) Inch |
1.4567 |
| Width (B) Inch |
0.4724 |
| Weight (kg) |
0.061 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
Z - Steel Seal on One Side |
| Cage Type |
P - Plastic Molded Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Lubrication |
Higher and Lower Temperature Grease |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Suffix description
| Z |
Shield Of Pressed Sheet Steel On One Side Of The Bearing |
| TN9 |
Injection Moulded Snap-Type Cage Of Glass Fibre Reinforced Polyamide 6,6, Ball Centered |
| C3 |
Internal Clearance Larger Than Normal |
| MT33 |
Lithium Grease, Medium Temp. 74 cSt @ 40°C, -30°C/+120°C, A Two-Figure Number Following MT Identifies The Actual Grease. An Additional Letter Or Letter/Figure Combination As Mentioned Under "HT" Identifies Filling Degrees Other Than Standard. Examples: MT33 Or MT37F9 |
