SKF 6212M/C3VL0241 Image 2
Visual product photo and picture of the product.
Price: 2,086.38 $
Specifications
Weight and Dimensions
| Inner (d) MM |
60 |
| Outer (D) MM |
110 |
| Width (B) MM |
22 |
| Inner (d) Inch |
2.3622 |
| Outer (D) Inch |
4.3307 |
| Width (B) Inch |
0.8661 |
| Weight (kg) |
0.86 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Breakdown Voltage 1000v |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Suffix description
| M |
Machined Brass Cage, Ball Centered; Different Designs And Material Grades Are Identified By A Figure Following The M, e.g. M2 |
| C3 |
Internal Clearance Larger Than Normal |
| VL0241 |
Electrical Resistance: Min. 50Mu03a9, Breakdown Voltage: Max. Operating Voltage 1.000v DC |
