SKF 6209-2RZTN9/HC5C3WT

SKF 6209-2RZTN9/HC5C3WT
SKF 6209-2RZTN9/HC5C3WT rulman resim 1
SKF 6209-2RZTN9/HC5C3WT rulman resim 2
SKF 6209-2RZTN9/HC5C3WT rulman resim 3
Price: 400.57 $
Specifications
Brand SKF
Item Number 6209-2RZTN9/HC5C3WT SKF
Also known as 6209-2RZTN9/HC5C3
EAN 7316571642352
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 85
Width (B) MM 19
Inner (d) Inch 1.7717
Outer (D) Inch 3.3465
Width (B) Inch 0.748
Weight (kg) 0.376 kg
Product Properties
Bore C - Cylindrical Bore
Seal 2RZ - Rubber and Steel Seal
Cage Type P - Plastic Molded Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision H5 - Ceramic Ball Set
Lubrication High Temperature Grease
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Suffix description
2RZ Ball Bearing, With Low-Friction Seal At Both Sides. Seal Consists Of Sheet Steel Washer With Vulcanized Rubber
TN9 Injection Moulded Snap-Type Cage Of Glass Fibre Reinforced Polyamide 6,6, Ball Centered
HC5 Rolling Elements Of Silicon Nitride
C3 Internal Clearance Larger Than Normal
WT Grease Fill For Low As Well As High Temperature e.g. Range -40 ~ 160°C. WT Or A Two-Figure Number Following WT Identifies The Actual Grease. An Additional Letter Or Letter/ Figure Combination As Mentioned Under u201cHTu201d Identifies Filling Degrees Other Than Standard
