SKF 6024-Z/S1LHT30VS042 Image 2
Visual product photo and picture of the product.
Price: 257.68 $
Specifications
Weight and Dimensions
| Inner (d) MM |
120 |
| Outer (D) MM |
180 |
| Width (B) MM |
28 |
| Inner (d) Inch |
4.7244 |
| Outer (D) Inch |
7.0866 |
| Width (B) Inch |
1.1024 |
| Weight (kg) |
2.11 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
Z - Steel Seal on One Side |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Higher and Lower Temperature Grease |
| Heat Stabilization |
S1 - Temperatures up to 200 °C |
| Special Treatment |
No Special Treatment |
Suffix description
| Z |
Shield Of Pressed Sheet Steel On One Side Of The Bearing |
| S1 |
Bearing Rings Or Washers Dimensionally Stabilized For Use At Operating Temperatures Up To +200°C (392°F) |
| LHT30 |
Lithium Grease, Wide Range, 74 cSt St 40°C, -40°C/+180°C. A Two-Figure Number Following LHT Identifies The Actual Grease |
| VS042 |
Clearance And Preload Modifications |
