SKF 3212A-2Z/C3MT33 Image 2
Visual product photo and picture of the product.
Price: 122.44 $
Specifications
Weight and Dimensions
| Inner (d) MM |
60 |
| Outer (D) MM |
110 |
| Width (B) MM |
36,5 |
| Inner (d) Inch |
2.3622 |
| Outer (D) Inch |
4.3307 |
| Width (B) Inch |
1.437 |
| Weight (kg) |
1.249 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
ZZ/2Z - Steel Seal on Two Sides |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Lubrication |
M - Grease with Lithium Thickener |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Standard |
Suffix description
| A |
Double Row Angular Contact Ball Bearing Without Filling Slots |
| 2Z |
Shield Of Pressed Sheet Steel On Both Sides Of The Bearing |
| C3 |
Internal Clearance Larger Than Normal |
| MT33 |
Lithium Grease, Medium Temp. 74 cSt @ 40°C, -30 ~ 120°C, A Two-Figure Number Following MT Identifies The Actual Grease. An Additional Letter Or Letter/Figure Combination As Mentioned Under "HT" Identifies Filling Degrees Other Than Standard. Examples: MT33 Or MT37F9 |
