SKF 3203A-2ZTN9/MT33 Image 2
Visual product photo and picture of the product.
Price: 24.39 $
Specifications
Weight and Dimensions
| Inner (d) MM |
17 |
| Outer (D) MM |
40 |
| Width (B) MM |
17,5 |
| Inner (d) Inch |
0.6693 |
| Outer (D) Inch |
1.5748 |
| Width (B) Inch |
0.689 |
| Weight (kg) |
0.1 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
ZZ/2Z - Steel Seal on Two Sides |
| Cage Type |
P - Plastic Molded Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
M - Grease with Lithium Thickener |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Standard |
Suffix description
| A |
Double Row Angular Contact Ball Bearing Without Filling Slots |
| 2Z |
Shield Of Pressed Sheet Steel On Both Sides Of The Bearing |
| TN9 |
Injection Moulded Snap-Type Cage Of Glass Fibre Reinforced Polyamide 6,6, Ball Centered |
| MT33 |
Lithium Grease, Medium Temp. 74 cSt @ 40°C, -30 ~ 120°C, A Two-Figure Number Following MT Identifies The Actual Grease. An Additional Letter Or Letter/Figure Combination As Mentioned Under "HT" Identifies Filling Degrees Other Than Standard. Examples: MT33 Or MT37F9 |
