RHP 7011CSN24TRSULP3 Image 3
Visual product photo and picture of the product.
Price: 802.57 $
Specifications
Weight and Dimensions
| Inner (d) MM |
55 |
| Outer (D) MM |
90 |
| Width (B) MM |
18 |
| Inner (d) Inch |
2.1654 |
| Outer (D) Inch |
3.5433 |
| Width (B) Inch |
0.7087 |
| Weight (kg) |
0.36 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
NS - Ceramic Balls |
| Contact Angle |
15 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
GA - Light Preload |
| Lubrication |
Standard Lubrication |
Suffix description
| C |
15° Contact Angle |
| SN24 |
Ceramic Ball (Small Ball Series) |
| TR |
Outer Ring Guided Phenolic Cage |
| SUL |
Single Ball Bearing, Angular Contact, Super Precision, Single Bearing Ground For Universal Mounting, Light Preload |
| P3 |
Dimensional Accuracy P4, Running Accuracy P2 |
