NSK 7208CTYNP5

NSK 7208CTYNP5
NSK 7208CTYNP5 rulman resim 1
NSK 7208CTYNP5 rulman resim 2
NSK 7208CTYNP5 rulman resim 3
Price: 86.00 $
Specifications
Brand NSK
Item Number 7208CTYNP5 NSK
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 80
Width (B) MM 18
Inner (d) Inch 1.5748
Outer (D) Inch 3.1496
Width (B) Inch 0.7087
Weight (kg) 0.36 kg
Product Properties
Seal No Seal
Cage Type P - Plastic Molded Cage
Precision P5 Precision (Higher than P6)
Contact Angle 15 degrees
Pairing No pairing
Axial Internal Clearance / Preload No Preload
Lubrication Standard Lubrication
Suffix description
C 15° Contact Angle
TYN This Special Design Allows The Bearing To Have Lower Friction And Lower Noise. The Temperature Rise Of The Bearing With A TYN Cage Is Lower Than That With A Phenolic Cage At A Rotational Speed Lower Than 1.4 Million DmN* ("Dm
N Pitch Circle Diameter Of Rolling Elements (mm)" x "Speed" (Min-1"))
P5 Dimensional And Running Accuracy To ISO Tolerance Class 5
