FAG 6208-Z-C3

FAG 6208-Z-C3
FAG 6208-Z-C3 rulman resim 1
FAG 6208-Z-C3 rulman resim 2
FAG 6208-Z-C3 rulman resim 3
FAG 6208-Z-C3 rulman resim 4
FAG 6208-Z-C3 rulman resim 5
Price: 12.84 $
Specifications
Brand FAG
Item Number 6208-Z-C3 FAG
Manufacturer Part Number 0167204900030
Also known as 6208-C-Z-C3
EAN 4012801070942
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 80
Width (B) MM 18
Inner (d) Inch 1.5748
Outer (D) Inch 3.1496
Width (B) Inch 0.7087
Weight (kg) 0.369 kg
Product Properties
Bore C - Cylindrical Bore
Seal Z - Steel Seal on One Side
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 18
Basic static load rating, radial (C 0r) 17800
Limiting speed (n G) 12300
Reference speed (n u03d1r) 9300
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Suffix description
Z Shield Of Pressed Sheet Steel On One Side Of The Bearing
C3 Internal Clearance Larger Than Normal
