NSK 7204ATYNDFMP5 Image 3
Visual product photo and picture of the product.
Price: 175.26 $
Specifications
Weight and Dimensions
| Inner (d) MM |
20 |
| Outer (D) MM |
47 |
| Width (B) MM |
28 |
| Inner (d) Inch |
0.7874 |
| Outer (D) Inch |
1.8504 |
| Width (B) Inch |
1.1024 |
| Weight (kg) |
0.2 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
P - Plastic Molded Cage |
| Precision |
P5 Precision (Higher than P6) |
| Contact Angle |
30 degrees |
| Pairing |
DF - X-arrangement, 2 |
| Axial Internal Clearance / Preload |
GB - Medium Preload |
| Lubrication |
Standard Lubrication |
Suffix description
| A |
30° Contact Angle |
| TYN |
This Special Design Allows The Bearing To Have Lower Friction And Lower Noise. The Temperature Rise Of The Bearing With A TYN Cage Is Lower Than That With A Phenolic Cage At A Rotational Speed Lower Than 1.4 Million DmN* ("Dm |
| N |
Pitch Circle Diameter Of Rolling Elements (mm)" x "Speed" (Min-1")) |
| DFM |
Matched Bearing Pair Arranged Face-To-Face, Medium Preload |
| P5 |
Dimensional And Running Accuracy To ISO Tolerance Class 5 |
