NKE NU213-E-M6-C3-SQ77 Image 2

Visual product photo and picture of the product.

NKE NU213-E-M6-C3-SQ77 bearing image 2
NKE NU213-E-M6-C3-SQ77 bearing image 1
NKE NU213-E-M6-C3-SQ77 bearing image 2
NKE NU213-E-M6-C3-SQ77 bearing image 3
NKE NU213-E-M6-C3-SQ77 bearing image 4
Price: 376.46 $
Specifications
Brand NKE
Item Number NU213-E-M6-C3-SQ77 NKE
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 65
Outer (D) MM 120
Width (B) MM 23
Weight (kg) 1.25 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Breakdown Voltage 1000v
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Suffix description
E Increased Load Capacity
M6 Roller Guided Solid Brass Cage For Cylindrical Roller Bearings, Cage Body Designed With Trapezoid-Shaped Machined Rivets
C3 Internal Clearance Larger Than Normal
SQ77 Outer Ring Isolated Up To 1000 Volt
