INA ZKLR0828-2Z
Price: 144.49 $
Specifications
| Brand | INA |
| Item Number | ZKLR0828-2Z INA |
| Manufacturer Part Number | 0041975180000 |
| EAN | 4054369574067 |
| Category | Angular Contact Ball Bearing Double Row |
| Inner (d) MM | 8 |
| Outer (D) MM | 23,9 |
| Width (B) MM | 15,5 |
| Inner (d) Inch | 0.315 |
| Outer (D) Inch | 0.9409 |
| Width (B) Inch | 0.6102 |
| Weight (kg) | 0.03 kg |
| Bore | C - Cylindrical Bore |
| Seal | ZZ/2Z - Steel Seal on Two Sides |
| Cage Type | S - Steel or Standard Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Split inner ring |
| Outside diameter bearing pot (D) mm | 23,9 |
| Radial Static Load Rating C0r (N) | 2700 |
| Width inner ring (B) mm | 14 |
| Radial Dynamic Load Rating Cr (N) | 5000 |
| Axial Static Load Rating C0a (N) | 1850 |
| Axial Dynamic Load Rating Ca (N) | 2060 |
| ECLASS number | 23-05-16-02 |
| ECLASS2 number | 23-05-16-02 |
| Medias description | Angular contact ball bearing units ZKLR..-2Z, double direction, for screw mounting, gap seals on both sides |
| 2Z | Gap Seals At Both Sides Of The Bearing |
