INA ZKLFA0630-2Z Image 6
Visual product photo and picture of the product.
Price: 396.00 $
Specifications
Weight and Dimensions
| Inner (d) MM |
6 |
| Outer (D) MM |
19 |
| Width (B) MM |
12 |
| Inner (d) Inch |
0.2362 |
| Outer (D) Inch |
0.748 |
| Width (B) Inch |
0.4724 |
| Weight (kg) |
0.05 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
ZZ/2Z - Steel Seal on Two Sides |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Split inner ring |
Data from Schaeffler (medias)
| Width (b) mm |
12 |
| Axial Static Load Rating C0a (N) |
6100 |
| Axial Dynamic Load Rating Ca (N) |
4900 |
| Limiting speed for grease lubrication (n G Grease) |
22800 |
| Thermally permissible speed (n u03d1) |
14000 |
| ECLASS number |
23-05-10-02 |
| ECLASS2 number |
23-05-10-02 |
| Medias description |
Angular contact ball bearing units ZKLFA..-2Z, double direction, for screw mounting, gap seals on both sides |
Suffix description
| 2Z |
Gap Seals At Both Sides Of The Bearing |
