INA TME40-XL-N Image 4

Visual product photo and picture of the product.

INA TME40-XL-N bearing image 4
INA TME40-XL-N bearing image 1
INA TME40-XL-N bearing image 2
INA TME40-XL-N bearing image 3
INA TME40-XL-N bearing image 4
INA TME40-XL-N bearing image 5
Price: 78.71 $
Specifications
Brand INA
Item Number TME40-XL-N INA
Manufacturer Part Number 0009425020000
Also known as TME40-N
EAN 4012802803945
Category Housing and Bearing (assembly)
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 145
Width (B) MM 56,5
Inner (d) Inch 1.5748
Outer (D) Inch 5.7087
Width (B) Inch 2.2244
Weight (kg) 1.77 kg
Product Properties
Seal 2T - Two T-seals
Lubrication Standard Lubrication
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Height flange (H) mm 145
Locking collar total width (B 1) mm 56,5
Total height unit (U) mm 33,9
Radial Static Load Rating C0r (N) 19800
Radial Dynamic Load Rating Cr (N) 34500
Basic static load rating, radial (C 0r) "19800.0000"
ECLASS number 23-05-16-02
ECLASS2 number 23-05-16-02
Medias description Flanged housing unit TME..-XL-N
Suffix description
XL X-Life
N Cast Iron Housing With Undercut Slot For End Caps
