INA TCJT40-XL-N

Specifications

Brand	INA
Item Number	TCJT40-XL-N INA
Manufacturer Part Number	0008569400000
Also known as	TCJT40-N
EAN	4012802799019
Category	Housing and Bearing (assembly)

Weight and Dimensions

Inner (d) MM	40
Outer (D) MM	172
Width (B) MM	59,1
Inner (d) Inch	1.5748
Outer (D) Inch	6.7717
Width (B) Inch	2.3268
Weight (kg)	1.7 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Flange width (L) mm	105
Height flange (H) mm	172
Total height unit (U) mm	59,1
Radial Static Load Rating C0r (N)	19800
Radial Dynamic Load Rating Cr (N)	34500
Basic static load rating, radial (C 0r)	"19800.0000"
ECLASS number	23-05-16-02
ECLASS2 number	23-05-16-02
Medias description	Housing units TCJT, two-bolt flanged housing units, cast iron, eccentric locking collar, T seals

Suffix description

XL	X-Life
N	Cast Iron Housing With Undercut Slot For End Caps
