INA LCJT40-XL-N-SML

Specifications

Brand	INA
Item Number	LCJT40-XL-N-SML INA
Manufacturer Part Number	0008578070319
Also known as	LCJT40-N-SML
EAN	4012802798111
Category	Housing and Bearing (assembly)

Weight and Dimensions

Inner (d) MM	40
Outer (D) MM	172
Width (B) MM	59,1
Inner (d) Inch	1.5748
Outer (D) Inch	6.7717
Width (B) Inch	2.3268
Weight (kg)	1.66 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Flange width (L) mm	105
Height flange (H) mm	172
Total height unit (U) mm	59,1
Radial Static Load Rating C0r (N)	19800
Radial Dynamic Load Rating Cr (N)	34500
Basic static load rating, radial (C 0r)	"19800.0000"
ECLASS number	23-05-16-02
ECLASS2 number	23-05-16-02
Medias description	Housing units LCJT, two-bolt flanged housing units, cast iron, eccentric locking collar, L seals, for temperatures from -40°C to +180°C

Suffix description

XL	X-Life
N	Cast Iron Housing With Undercut Slot For End Caps
SML	More Clearance Between Bearings And Housing, This Has No Influence On The Item Without The Suffix SML
