INA TCJL30-N-L285 Image 2

Visual product photo and picture of the product.

INA TCJL30-N-L285 bearing image 2
INA TCJL30-N-L285 bearing image 1
INA TCJL30-N-L285 bearing image 2
Price: 68.16 $
Specifications
Brand INA
Item Number TCJL30-N-L285 INA
Manufacturer Part Number 0027434340000
Also known as GLE30-KTT-B-L285 + GGCJ06
EAN 4012802813395
Category Housing and Bearing (assembly)
Weight and Dimensions
Inner (d) MM 30
Outer (D) MM 170
Width (B) MM 40
Inner (d) Inch 1.1811
Outer (D) Inch 6.6929
Width (B) Inch 1.5748
Weight (kg) 1.065 kg
Product Properties
Seal ZZ/2Z - Steel Seal on Two Sides
Lubrication Standard Lubrication
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Flange width (L) mm 108
Total height unit (U) mm 42
Radial Static Load Rating C0r (N) 11300
Radial Dynamic Load Rating Cr (N) 20700
Basic static load rating, radial (C 0r) "11300.0000"
ECLASS number 23-05-16-02
ECLASS2 number 23-05-16-02
Medias description Flanged housing unit TCJL..-N
Suffix description
N Cast Iron Housing With Undercut Slot For End Caps
L285 Lubricant (Grease L285)
