INA SL185008-S3-A-C4 Image 3
Visual product photo and picture of the product.
Price: 162.27 $
Specifications
Weight and Dimensions
| Inner (d) MM |
40 |
| Outer (D) MM |
68 |
| Width (B) MM |
38 |
| Inner (d) Inch |
1.5748 |
| Outer (D) Inch |
2.6772 |
| Width (B) Inch |
1.4961 |
| Weight (kg) |
0.56 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
FC - Full Complement, No Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C4 Internal Play (Higher than C3) |
| Precision |
Standard Precision |
| Heat Stabilization |
S3 - Temperatures up to 300 °C |
Data from Schaeffler (medias)
| Width (b) mm |
38 |
| Basic static load rating, radial (C 0r) |
133000 |
| Limiting speed (n G) |
6300 |
| Reference speed (n u03d1r) |
4200 |
| ECLASS number |
23-05-09-01 |
| ECLASS2 number |
23-05-09-01 |
Suffix description
| S3 |
Bearing Rings Or Washers Dimensionally Stabilized For Use At Operating Temperatures Up To +300°C (572°F) |
| A |
The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
| C4 |
Bearing Internal Clearance Greater Than C3 |
