INA SL045026-D-PP-2NR-C3 Image 2
Visual product photo and picture of the product.
Price: 908.93 $
Specifications
Weight and Dimensions
| Inner (d) MM |
130 |
| Outer (D) MM |
200 |
| Width (B) MM |
95 |
| Inner (d) Inch |
5.1181 |
| Outer (D) Inch |
7.874 |
| Width (B) Inch |
3.7402 |
| Weight (kg) |
10.5 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
2L - LS-seal at Both Sides |
| Cage Type |
FC - Full Complement, No Cage |
| External Modification |
2R - 2 Snap Rings in O.D. |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Width (b) mm |
95 |
| Basic static load rating, radial (C 0r) |
960000 |
| Limiting speed for grease lubrication (n G Grease) |
960 |
Suffix description
| D |
Outer Ring Profile Developed Further, With An Enlarged Load Bearing Area And Optimized Edge Transitions |
| PP |
Lip Seals On Both Sides Of The Bearing |
| 2NR |
Supplied With Two Loose-Packed Retaining Rings WRE |
| C3 |
Internal Clearance Larger Than Normal |
