INA SL045018-D-PP-2NR-C3-GA22 Image 2
Visual product photo and picture of the product.
Price: 545.96 $
Specifications
Weight and Dimensions
| Inner (d) MM |
90 |
| Outer (D) MM |
140 |
| Width (B) MM |
67 |
| Inner (d) Inch |
3.5433 |
| Outer (D) Inch |
5.5118 |
| Width (B) Inch |
2.6378 |
| Weight (kg) |
3.55 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
2L - LS-seal at Both Sides |
| Cage Type |
FC - Full Complement, No Cage |
| External Modification |
2R - 2 Snap Rings in O.D. |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Grease -50°C / +120°C |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Width (b) mm |
67 |
| Basic static load rating, radial (C 0r) |
510000 |
| Limiting speed for grease lubrication (n G Grease) |
1410 |
Suffix description
| D |
Outer Ring Profile Developed Further, With An Enlarged Load Bearing Area And Optimized Edge Transitions |
| PP |
Lip Seals On Both Sides Of The Bearing |
| 2NR |
Supplied With Two Loose-Packed Retaining Rings WRE |
| C3 |
Internal Clearance Larger Than Normal |
| GA22 |
Optimized Grease For All Purposes, Temperature Range Approximately -50 ~ 120°C - Description: Isoflex® LDS 18 Special A)-Is A Dynamically Light Long-Term Grease For Plain And Rolling Bearings. It Consists Of Ester Oil, Mineral Oil And Lithium Soap. The Product Is Resistant To Ageing, Oxidation And Water, And It Protects Reliably Against Corrosion. Application: Isoflex® LDS 18 Special A Is Suitable For Plain And Rolling Bearings Operating At Low Temperatures And/Or High Speeds, For Example In Grinding Spindles, Machine Tool Spindles, Spindle Bearings, Textile Spindles, Bearings In Oe-Spinning Turbines, Bearings In Precision And Optical Equipment |
