INA SL045007-PP-2NR Image 4
Visual product photo and picture of the product.
Price: 101.57 $
Specifications
Weight and Dimensions
| Inner (d) MM |
35 |
| Outer (D) MM |
62 |
| Width (B) MM |
36 |
| Inner (d) Inch |
1.378 |
| Outer (D) Inch |
2.4409 |
| Width (B) Inch |
1.4173 |
| Weight (kg) |
0.48 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
2L - LS-seal at Both Sides |
| Cage Type |
FC - Full Complement, No Cage |
| External Modification |
2R - 2 Snap Rings in O.D. |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Width (b) mm |
36 |
| Radial Static Load Rating C0r (N) |
88000 |
| Radial Dynamic Load Rating Cr (N) |
63000 |
| Basic static load rating, radial (C 0r) |
"88000.0000" |
| Limiting speed for grease lubrication (n G Grease) |
3550 |
| ECLASS number |
23-05-09-01 |
| ECLASS2 number |
23-05-09-01 |
| Medias description |
Cylindrical roller bearing SL04..-PP-2NR, full complement roller set, two-row, locating bearing, central rib on outer ring, 3 ribs on inner ring, type SL04 |
Suffix description
| PP |
Lip Seals On Both Sides Of The Bearing |
| 2NR |
Supplied With Two Loose-Packed Retaining Rings WRE |
