INA SL04100-D-PP Image 3
Visual product photo and picture of the product.
Price: 747.66 $
Specifications
Weight and Dimensions
| Inner (d) MM |
100 |
| Inner (d) Inch |
3.937 |
| Weight (kg) |
6.5 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
2L - LS-seal at Both Sides |
| Cage Type |
FC - Full Complement, No Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Width (b) mm |
80 |
| Radial Static Load Rating C0r (N) |
630000 |
| Radial Dynamic Load Rating Cr (N) |
380000 |
| Basic static load rating, radial (C 0r) |
"630000.0000" |
| Limiting speed for grease lubrication (n G Grease) |
1260 |
| ECLASS number |
23-05-09-01 |
| ECLASS2 number |
23-05-09-01 |
| Medias description |
Cylindrical roller bearing SL04..-D-PP, full complement roller set, two-row, locating bearing, central rib on outer ring, 3 ribs on inner ring, type SL04 |
Suffix description
| D |
Outer Ring Profile Developed Further, With An Enlarged Load Bearing Area And Optimized Edge Transitions |
| PP |
Lip Seals On Both Sides Of The Bearing |
