INA RWU55-E-H-V3-G1 Image 4
Visual product photo and picture of the product.
Price: 480.35 $
Specifications
Weight and Dimensions
| Inner (d) MM |
53 |
| Outer (D) MM |
100 |
| Width (B) MM |
69 |
| Inner (d) Inch |
2.0866 |
| Outer (D) Inch |
3.937 |
| Width (B) Inch |
2.7165 |
| Weight (kg) |
4.94 kg
|
Product Properties
Data from Schaeffler (medias)
| Width carriage (B) mm |
100 |
| Overall length carriage (L) mm |
172,7 |
| Dynamic load rating (C) |
136000 |
| Dynamic load rating (C 0) |
320000 |
| Static moment rating about X axis (M 0x) |
3287 |
| Static moment rating about Y axis (M 0y) |
7404 |
| Static moment rating about Z axis (M 0z) |
6667 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
High, narrow carriage with full complement recirculating roller system for linear recirculating roller bearing and guideway assembly, for oil or grease lubrication |
Suffix description
| E |
Version |
| H |
High Carriage |
| V3 |
Preload Class 3 |
| G1 |
Precision Class 1 |
