INA RWU45-E-HL-V2-G3 Image 2
Visual product photo and picture of the product.
Price: 334.94 $
Specifications
Weight and Dimensions
| Inner (d) MM |
45 |
| Outer (D) MM |
86 |
| Width (B) MM |
178,3 |
| Inner (d) Inch |
1.7717 |
| Outer (D) Inch |
3.3858 |
| Width (B) Inch |
7.0197 |
| Weight (kg) |
3.95 kg
|
Product Properties
Data from Schaeffler (medias)
| Width carriage (B) mm |
86 |
| Overall length carriage (L) mm |
178,3 |
| Dynamic load rating (C) |
114000 |
| Dynamic load rating (C 0) |
285000 |
| Static moment rating about X axis (M 0x) |
2503 |
| Static moment rating about Y axis (M 0y) |
7263 |
| Static moment rating about Z axis (M 0z) |
6536 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
High, narrow, long carriage with full complement recirculating roller system for linear recirculating roller bearing and guideway assembly, for oil or grease lubrication |
Suffix description
| E |
Version |
| HL |
High, Long Carriage |
| V2 |
Preload Class 2 |
| G3 |
Precision Class 3 |
