INA RSL183012-A-XL Image 2
Visual product photo and picture of the product.
Price: 84.30 $
Specifications
Weight and Dimensions
| Inner (d) MM |
60 |
| Outer (D) MM |
86,74 |
| Width (B) MM |
26 |
| Inner (d) Inch |
2.3622 |
| Outer (D) Inch |
3.415 |
| Width (B) Inch |
1.0236 |
| Weight (kg) |
0.425 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
FC - Full Complement, No Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| E w mm |
86,74 |
| Width (b) mm |
26 |
| Radial Static Load Rating C0r (N) |
143000 |
| Radial Dynamic Load Rating Cr (N) |
123000 |
| Basic static load rating, radial (C 0r) |
"143000.0000" |
| Limiting speed (n G) |
4350 |
| ECLASS number |
23-05-09-01 |
| ECLASS2 number |
23-05-09-01 |
| Medias description |
Cylindrical roller bearing RSL1830..-XL, full complement roller set, single row, non-locating bearing, no outer ring, 2 ribs on inner ring, type RSL18 |
Suffix description
| A |
The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
| XL |
X-Life |
