INA RSL183005-A-XL-2S Image 3
Visual product photo and picture of the product.
Price: 34.14 $
Specifications
Weight and Dimensions
| Inner (d) MM |
25 |
| Outer (D) MM |
42,51 |
| Width (B) MM |
16 |
| Inner (d) Inch |
0.9843 |
| Outer (D) Inch |
1.6736 |
| Width (B) Inch |
0.6299 |
| Weight (kg) |
0.078 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
FC - Full Complement, No Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Set of Two for Side-by-Side |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| E w mm |
42,51 |
| Width (b) mm |
16 |
| Basic static load rating, radial (C 0r) |
32000 |
| Limiting speed (n G) |
9500 |
| ECLASS number |
23-05-09-01 |
| ECLASS2 number |
23-05-09-01 |
Suffix description
| A |
The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
| XL |
X-Life |
| 2S |
Bearings Matched In Set Of Two For Side-By-Side Mounting, Tolerance Is Matched Based On The Inner, Outer And Clearance Of The Bearing |
