INA RME35-XL-N Image 3
Visual product photo and picture of the product.
Price: 52.45 $
Specifications
Weight and Dimensions
| Inner (d) MM |
35 |
| Outer (D) MM |
135 |
| Width (B) MM |
43,3 |
| Inner (d) Inch |
1.378 |
| Outer (D) Inch |
5.315 |
| Width (B) Inch |
1.7047 |
| Weight (kg) |
1.7 kg
|
Product Properties
| Seal |
2F - Standard Seal for Y-bearings |
| Lubrication |
Standard Lubrication |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Height flange (H) mm |
135 |
| Locking collar total width (B 1) mm |
51,3 |
| Total height unit (U) mm |
31,3 |
| Radial Static Load Rating C0r (N) |
15300 |
| Radial Dynamic Load Rating Cr (N) |
27500 |
| Basic static load rating, radial (C 0r) |
"15300.0000" |
| ECLASS number |
23-05-16-02 |
| ECLASS2 number |
23-05-16-02 |
| Medias description |
Housing units RME, four-bolt flanged housing units, cast iron, centring spigot, eccentric locking collar, R seals |
Suffix description
| XL |
X-Life |
| N |
Cast Iron Housing With Undercut Slot For End Caps |
