INA RME20-XL-N Image 2
Visual product photo and picture of the product.
Price: 33.70 $
Specifications
Weight and Dimensions
| Inner (d) MM |
20 |
| Outer (D) MM |
100 |
| Width (B) MM |
36,6 |
| Inner (d) Inch |
0.7874 |
| Outer (D) Inch |
3.937 |
| Width (B) Inch |
1.4409 |
| Weight (kg) |
0.75 kg
|
Product Properties
| Seal |
2F - Standard Seal for Y-bearings |
| Lubrication |
Standard Lubrication |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Height flange (H) mm |
100 |
| Locking collar total width (B 1) mm |
43,7 |
| Total height unit (U) mm |
24,6 |
| Radial Static Load Rating C0r (N) |
6600 |
| Radial Dynamic Load Rating Cr (N) |
13600 |
| Basic static load rating, radial (C 0r) |
"6600.0000" |
| ECLASS number |
23-05-16-02 |
| ECLASS2 number |
23-05-16-02 |
| Medias description |
Housing units RME, four-bolt flanged housing units, cast iron, centring spigot, eccentric locking collar, R seals |
Suffix description
| XL |
X-Life |
| N |
Cast Iron Housing With Undercut Slot For End Caps |
