INA RCJTA20-XL-N

INA RCJTA20-XL-N
INA RCJTA20-XL-N rulman resim 1
INA RCJTA20-XL-N rulman resim 2
INA RCJTA20-XL-N rulman resim 3
INA RCJTA20-XL-N rulman resim 4
INA RCJTA20-XL-N rulman resim 5
Price: 43.85 $
Specifications
Brand INA
Item Number RCJTA20-XL-N INA
Manufacturer Part Number 0009526210000
Also known as GSH20-2RSR-B + GG.CJT04-N
EAN 4012802823622
Category Housing and Bearing (assembly)
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 112
Width (B) MM 42,5
Inner (d) Inch 0.7874
Outer (D) Inch 4.4094
Width (B) Inch 1.6732
Weight (kg) 0.52 kg
Product Properties
Seal 2F - Standard Seal for Y-bearings
Lubrication Standard Lubrication
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Flange width (L) mm 61
Height flange (H) mm 112
Total height unit (U) mm 42,5
Radial Static Load Rating C0r (N) 7000
Radial Dynamic Load Rating Cr (N) 13400
Basic static load rating, radial (C 0r) "6600.0000"
ECLASS number 23-05-16-02
ECLASS2 number 23-05-16-02
Medias description Housing units RCJTA, two-bolt flanged housing units, cast iron, adapter sleeve, R seals
Suffix description
XL X-Life
N Cast Iron Housing With Undercut Slot For End Caps
