INA PCJT20-XL-N

INA PCJT20-XL-N
INA PCJT20-XL-N rulman resim 1
INA PCJT20-XL-N rulman resim 2
INA PCJT20-XL-N rulman resim 3
INA PCJT20-XL-N rulman resim 4
Price: 26.80 $
Specifications
Brand INA
Item Number PCJT20-XL-N INA
Manufacturer Part Number 0096436130000
Also known as PCJT20-N
EAN 4012802837582
Category Housing and Bearing (assembly)
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 112
Width (B) MM 42,5
Inner (d) Inch 0.7874
Outer (D) Inch 4.4094
Width (B) Inch 1.6732
Weight (kg) 0.447 kg
Product Properties
Seal 2F - Standard Seal for Y-bearings
Lubrication Standard Lubrication
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Flange width (L) mm 61
Height flange (H) mm 112
Total height unit (U) mm 42,5
Radial Static Load Rating C0r (N) 6600
Radial Dynamic Load Rating Cr (N) 13600
Basic static load rating, radial (C 0r) "6600.0000"
ECLASS number 23-05-16-02
ECLASS2 number 23-05-16-02
Medias description Housing units PCJT, two-bolt flanged housing units, cast iron, eccentric locking collar, P seals
Suffix description
XL X-Life
N Cast Iron Housing With Undercut Slot For End Caps
