INA RCJ35-XL-FA164 Image 3
Visual product photo and picture of the product.
Price: 369.32 $
Specifications
Weight and Dimensions
| Inner (d) MM |
35 |
| Outer (D) MM |
118 |
| Width (B) MM |
53,3 |
| Inner (d) Inch |
1.378 |
| Outer (D) Inch |
4.6457 |
| Width (B) Inch |
2.0984 |
| Weight (kg) |
1.445 kg
|
Product Properties
| Seal |
2F - Standard Seal for Y-bearings |
| Lubrication |
Standard Lubrication |
| Special Treatment |
E - High Temp Design Up to +250°C |
Data from Schaeffler (medias)
| Flange width (L) mm |
118 |
| Total height unit (U) mm |
53,5 |
| Radial Static Load Rating C0r (N) |
15300 |
| Radial Dynamic Load Rating Cr (N) |
27500 |
| Basic static load rating, radial (C 0r) |
"15300.0000" |
| ECLASS number |
23-05-16-02 |
| ECLASS2 number |
23-05-16-02 |
| Medias description |
Housing units RCJ..-FA164, four-bolt flanged housing units, cast iron, eccentric locking collar, R seals, for temperatures up to +250°C |
Suffix description
| XL |
X-Life |
| FA164 |
High Temperature Design Up To +250°C |
