INA RAT20-XL Image 4
Visual product photo and picture of the product.
Price: 20.06 $
Specifications
Weight and Dimensions
| Inner (d) MM |
20 |
| Outer (D) MM |
91 |
| Width (B) MM |
25,5 |
| Inner (d) Inch |
0.7874 |
| Outer (D) Inch |
3.5827 |
| Width (B) Inch |
1.0039 |
| Weight (kg) |
0.23 kg
|
Product Properties
| Seal |
2F - Standard Seal for Y-bearings |
| Lubrication |
Standard Lubrication |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Flange width (L) mm |
66 |
| Height flange (H) mm |
90,5 |
| Total height unit (U) mm |
25,5 |
| Radial Static Load Rating C0r (N) |
6600 |
| Radial Dynamic Load Rating Cr (N) |
13600 |
| Basic static load rating, radial (C 0r) |
"6600.0000" |
| Load carrying capacity (housing) (C 0r G) |
3200 |
| Load carrying capacity (housing) (C g) |
3200 |
| ECLASS number |
23-05-16-02 |
| ECLASS2 number |
23-05-16-02 |
| Medias description |
Housing units RAT, two-bolt flanged housing units, sheet steel, eccentric locking collar, P seals |
Suffix description
